Fairchild FSL136MR Power Switch Datasheet
The FSL136MR is an integrated Pulse Width Modulator (PWM) and SenseFET designed for high-performance offline Switch-Mode Power Supplies (SMPS). It features an internal avalanche-rugged SenseFET with 650V rating and is optimized for applications requiring minimal external components, such as VCR, STB, DVD, and home appliance power adapters.
Read onlineAll Fairchild FSL136MR documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
Does the FSL136MR include built-in soft-start?
Yes, the integrated PWM controller includes a built-in soft-start with a time of 15ms.
Does the FSL136MRT include a built-in soft-start?
Yes, it includes a built-in soft-start with a time of 15ms.
From: Fairchild Semiconductor FSL136MRT Green-Mode Fairchild Power Switch Datasheet
What are the protection functions of the FSL136MRT?
It includes Overload Protection (OLP), Over-Voltage Protection (OVP), Abnormal Over-Current Protection (AOCP), and Internal Thermal Shutdown (TSD).
From: Fairchild Semiconductor FSL136MRT Green-Mode Fairchild Power Switch Datasheet
