Start here
Fairchild Semiconductor AN-5026 Using BGA Packages Application Note
The document introduces the Fine-Pitch Ball Grid Array (FBGA) package as a solution to space and weight requirements in personal computing and portable electronics. It highlights BGA advantages such as smaller size, larger pitch, lack of fragile leads, improved board assembly yields, and better thermal properties compared to QFP or TSSOP packages.
The note provides detailed routing techniques for different bit-count devices (18-bit, 24-bit, 32-bit, 36-bit, 40-bit, and 48-bit) using specific Fairchild models like the 74LCX16500 and FST32211. It also covers power and ground routing methods via vias under or outside the package, as well as advanced via types including blind, buried, and micro vias for high-density designs.
Fairchild AN-5026 specifications
| Input Voltage Range | 3V to 16V |
|---|---|
| Output Voltage Range | 0.9V to 5.5V |
| Operating Temperature | -40°C to +85°C |
| Package Type | 28-Lead Thin-Shrink Small-Outline Package (TSSOP) |
| Oscillator Frequency | 255 kHz to 345 kHz |
| Internal Reference Voltage | 0.900V |
Source: Fairchild Semiconductor FAN5026 Dual DDR / Dual-Output PWM Controller Datasheet
All Fairchild AN-5026 documents by type
How to use the product for one specific task, with worked examples.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What are the main advantages of BGA packages compared to fine pitch QFP or TSSOP?
BGAs are usually smaller, have larger pitch, and lack fragile leads that cause yield and rework problems.
From: Fairchild Semiconductor AN-5026 Using BGA Packages Application Note
What is the standard ball pitch for Fairchild Semiconductor BGA products?
Fairchild Semiconductor BGA products are designed around a JEDEC standard 0.8mm ball pitch.
From: Fairchild Semiconductor AN-5026 Using BGA Packages Application Note
What is the input voltage range for the FAN5026?
The controller supports a wide input range from 3V to 16V.
From: Fairchild Semiconductor FAN5026 Dual DDR / Dual-Output PWM Controller Datasheet
What package does the FAN5026 come in?
The device is available in a 28-Lead Thin-Shrink Small-Outline Package (TSSOP).
From: Fairchild Semiconductor FAN5026 Dual DDR / Dual-Output PWM Controller Datasheet
What is the input voltage range for the FAN5026?
The controller operates with an input voltage from 3 V up to 16 V.
From: Fairchild FAN5026 Dual DDR/Dual-Output PWM Controller Datasheet
How many output regulators does the FAN5026 provide?
It provides two independent output regulators that can be configured for DDR mode or independent operation.
From: Fairchild FAN5026 Dual DDR/Dual-Output PWM Controller Datasheet
