Key facts
- Brand
- Fairchild
- Model
- 74LVX3245
- Category
- Other Electronics
- Documents
- 2
- Languages
- EN
- Last added
- 2012-08-01
Start here
Fairchild AN-5001 LVX Translating Transceivers Application Note
Application Note 3 pages · 27 KB · EN
Fairchild Semiconductor's LVX Low Voltage Dual Supply CMOS Translating Transceivers (74LVX3245, 74LVX4245, 74LVXC3245, and 74LVXC4245) are designed to interface between 3 volt and 5 volt logic systems. These true voltage translating devices electrically isolate the A-side from the B-side to ensure clean signal translation.
Read onlineAll Fairchild 74LVX3245 documents by type
Application Note 1
How to use the product for one specific task, with worked examples.
Other documents 1
Questions answered in these manuals
What voltage levels can the 74LVX3245 and 74LVX4245 devices translate between?
These devices are designed to interface 3 volt signals to 5 volt signals.
From: Fairchild AN-5001 LVX Translating Transceivers Application Note
What voltage range is acceptable for the higher voltage side of the 74LVX3245?
The higher voltage Vcc side is able to swing from 4.5V to 5.5V.
From: Fairchild AN-5001 LVX Translating Transceivers Application Note
