Fairchild FODM8061 High-Speed Logic Compatible Optocoupler Datasheet
The document provides technical specifications for the FODM8061, a dual-chip optical hybrid device. It features an infrared LED input coupled to a phototransistor output via a linear amplifier, designed for high-speed data transmission up to 20 Mbit/s.
Key characteristics include compatibility with standard logic levels (3.3V and 5V), operation over a temperature range of -40°C to +110°C, and the use of Fairchild's Optoplanar packaging technology to minimize common-mode noise coupling. This manual is written in Chinese.
Fairchild FODM8061 specifications
| Operating Temperature Range | -40°C to +110°C |
|---|---|
| Maximum Data Rate | 20 Mbit/s |
| Package Type | SO-5 Mini-Flat |
Source: Fairchild FODM8061 High-Speed Logic Compatible Optocoupler Datasheet
All Fairchild FODM8061 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the typical current transfer ratio (CTR) at Vcc=3.3V?
The minimum CTR should be 260% and the typical CTR is 380%.
From: Fairchild FODM8061 High-Speed Logic Compatible Optocoupler Datasheet
Is the FODM8061 compatible with standard logic families?
Yes, it is compatible with 74HC/74HCT series logic.
From: Fairchild FODM8061 High-Speed Logic Compatible Optocoupler Datasheet
What is the maximum operating temperature?
The device operates over a temperature range of -40°C to +110°C.
Is this optocoupler compatible with 3.3V logic?
Yes, it supports 3.3V LVTTL/LVCMOS compatibility.
What is the typical propagation delay of the FODM8061?
A typical device offers a symmetrical high-to-low and low-to-high propagation delay of approximately 36ns.
From: FAIRCHILD AN-3012 Manual
Is the FODM8061 compatible with 3.3V logic supplies?
Yes, the high speed optical IC is specified with guaranteed performance at both 3.3V and 5V logic supplies.
From: FAIRCHILD AN-3012 Manual
