Agilent 1260 Infinity High Performance Micro Autosampler Features and Specifications
The Agilent 1260 Infinity High Performance Micro Autosampler is designed for capillary and nanoflow liquid chromatography (LC). It allows for the injection of sample volumes ranging from nanoliters to picoliters from well plates and vials. The system features a low dispersion micro injection valve and can be upgraded to a thermostatted version using the Agilent 1290 Infinity Thermostat.
Read onlineAgilent 1260 Infinity High Performance Micro specifications
| Injection range | 0.01 - 8 pL in 0.01 pL increments with the small loop capillary |
|---|---|
| Injection range | 0.01 - 40 pL in 0.01 pL increments with the extended loop capillary |
| Sample capacity | 2 well plates (96 and 384) plus 10 additional 2-mL vials |
| Injection cycle time | Typically < 30 s |
| Carryover | Typically < 0.05 % |
Source: Agilent 1260 Infinity High Performance Micro Autosampler Features and Specifications
All Agilent 1260 Infinity High Performance Micro documents by type
Questions answered in these manuals
What is the injection range for the small loop capillary?
The injection range is 0.01 to 8 pL in 0.01 pL increments.
From: Agilent 1260 Infinity High Performance Micro Autosampler Features and Specifications
Can the autosampler handle well plates?
Yes, it features flexible sample handling with different types of sample containers such as well-plates and vials.
From: Agilent 1260 Infinity High Performance Micro Autosampler Features and Specifications
