Texas Instruments TL1454 Manuals

Key facts

Brand: Texas Instruments
Model: TL1454
Category: Other Electronics
Documents: 3
Languages: EN
Last added: 2012-08-09

Start here

Texas Instruments TL145406 Triple RS-232 Drivers/Receivers Datasheet

Datasheet 10 pages · 149 KB · EN

The TL145406 is a bipolar integrated circuit containing three independent drivers and receivers designed to interface data terminal equipment (DTE) with data circuit-terminating equipment (DCE). The device meets or exceeds the requirements of ANSI EIA/TIA-232-E and ITU V.28 standards, supporting data rates up to 120 kbits/s over 3-meter cables. It is functionally interchangeable with the Motorola MC145406 and Texas Instruments SN75C1406.

Read online

Texas Instruments TL1454 specifications

Data Rate Support	Up to 120 kbits/s
ESD Protection	Exceeds 5 kV on All Pins
Supply Voltage Range	±4.5 V to ±15 V
Operating Temperature	0°C to 70°C
Number of Channels	Triple (3 independent)

Source: Texas Instruments TL145406 Triple RS-232 Drivers/Receivers Datasheet

All Texas Instruments TL1454 documents by type

Datasheet 3

Ratings, dimensions and ordering codes, for selection and design work.

Questions answered in these manuals

What standards does the TL145406 comply with?

It complies with the requirements of EIA/TIA 232-E and ITU V.28 standards.

From: Texas Instruments TL145406 Triple RS-232 Drivers/Receivers Datasheet

Is the TL145406 interchangeable with other models?

Yes, it is functionally interchangeable with the Motorola MC145406 and Texas Instruments SN75C1406.

From: Texas Instruments TL145406 Triple RS-232 Drivers/Receivers Datasheet

How is the oscillator frequency set?

The frequency is set between 50 kHz and 2 MHz using an external resistor connected between RT and GND and a capacitor between CT and GND.

From: Texas Instruments TL1454/TL1454Y Dual-Channel PWM Control Circuit Datasheet

What is the function of the short-circuit protection (SCP)?

The SCP function prevents damage to power switches when the converter output is shorted to ground by turning off the output drives and resetting the soft-start circuit.
