This document is the data manual for the TI TMS320VC5409 fixed-point digital signal processor. The processor was published in April 1999 and revised in February 2004. The manual provides technical specifications for the processor, as well as information on how to use it.
This data manual (Literature Number SPRS140F) presents the technical specifications of the TMS320VC5409A fixed‑point digital signal processor, including electrical characteristics, pin assignments for GGU and PGE packages, on‑chip peripherals and timing diagrams. It also contains revision history, mechanical drawings and package thermal‑resistance information.
Key sections cover functional overview, electrical specifications (absolute maximum ratings, recommended operating conditions, timing parameters), memory maps, DMA controller details, and mechanical data for the 144‑ball GGU BGA and 144‑pin PGE low‑profile QFP packages.
| Literature Number | SPRS140F |
|---|---|
| Output current limit Igy | -8 mA |
| Differential output voltage (DVpp) | 2.7 V to 3.0 V |
The literature number is SPRS140F.
The manual was revised in January 2005.
