Analog Devices ADuC702x Debug Manual
This document serves as a user guide for debugging the ADuC702x series of microcontrollers. It specifically addresses issues related to using the RDI Driver DLL with Keil uVision3, providing steps to resolve compatibility problems between the mIDAS-Link tool and specific versions of the development environment.
The manual outlines a step-by-step procedure for setting up a debugging session. This includes installing necessary drivers (such as J-Link), configuring the project in Keil uVision3 V3.22, selecting the correct device options, and utilizing the JLINKRDI.dll file to establish a connection with hardware evaluation boards like the EVAL-ADuC7026.
Analog Devices ADUC702X specifications
| Supported Models | ADuC7019/20/21/22/24/25/26/27/28 |
|---|---|
| Software Version | Keil uVision3 V3.22 |
| Required Hardware | EVAL-ADuC7026, mIDAS-Link JTAG |
