Start here
Analog Devices AD626 Datasheet
The AD626 is a low cost, true single supply differential amplifier designed for amplifying small differential voltages from sources having a large common-mode voltage. It operates from either a single supply of +2.4 V to +10 V or dual supplies of 1.2 V to ±6 V.
Key features include pin selectable gains of 10 and 100, input protection against continuous overload up to 50 V, and included RFI filters. The device is available in two 8-lead packages: a plastic mini-DIP and SOIC.
Analog Devices AD626 specifications
| Input Offset Voltage Max | 500 uV |
|---|---|
| Common-Mode Rejection Ratio Typ | 90 dB |
| Settling Time to 0.01% | 24 us |
| Operating Temperature Range | -40°C to +85°C |
| Input Resistance Differential | 200 kΩ |
Source: Analog Devices AD626 Datasheet
All Analog Devices AD626 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
- Analog Devices AD626 Datasheet 12 p
- Analog Devices AD626 Differential Amplifier Datasheet 12 p
- Analog Devices AD626 Low Cost Single‑Supply Differential Amplifier Datasheet 12 p
- Analog Devices AD626 Differential Amplifier Datasheet 12 p
- Analog Devices AD626 Low‑Cost Single‑Supply Differential Amplifier Datasheet 12 p
- Analog Devices AD626 Differential Amplifier Datasheet 12 p
- Analog Devices AD626 Datasheet 12 p
Questions answered in these manuals
What are the selectable gains for the AD626?
The amplifier provides a preset gain of 10, but gains between 10 to 100 can be easily configured with an external resistor.
What is the single supply voltage range?
The device supports a single supply range from +2.4 V to +10 V.
What gain options are available for the AD626?
The AD626 provides pin‑selectable gains of 10 or 100.
What is the input offset voltage of the AD626?
The device has a low input offset voltage of 500 pV maximum.
What gain options are available for the AD626?
The AD626 provides selectable gains of 10 and 100, set by connecting Pin 7 to ground for gain 100 or leaving it open for gain 10.
From: Analog Devices AD626 Low Cost Single‑Supply Differential Amplifier Datasheet
What is the typical common‑mode rejection ratio of the AD626?
The device achieves a typical common‑mode rejection ratio of about 90 dB.
From: Analog Devices AD626 Low Cost Single‑Supply Differential Amplifier Datasheet
