Key facts
- Brand
- Philips
- Model
- 74ABT16241A
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-12
Start here
PHILIPS 74ABT16241A 74ABTH16241A 16-bit buffer/driver (3-State) handbook(1)
This document is a product specification datasheet for the Philips 74ABT16241A and 74ABTH16241A, which are high-performance BICMOS 16-bit buffer/driver devices. These components are designed for driving bus lines and feature TTL input and output switching levels compatible with 5V supply systems.
Read onlinePhilips 74ABT16241A specifications
| Device Type | 16-bit buffer/driver (3-State) |
|---|---|
| Technology | BICMOS |
| Output Capability | +64mA/-32mA |
| Operating Temperature | -40°C to +85°C |
Source: PHILIPS 74ABT16241A 74ABTH16241A 16-bit buffer/driver (3-State) handbook(1)
All Philips 74ABT16241A documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
Do these devices require external pull-up resistors?
No, the bus-hold data inputs eliminate the need for external pull-up resistors to hold unused inputs.
From: PHILIPS 74ABT16241A 74ABTH16241A 16-bit buffer/driver (3-State) handbook(1)
What is the typical propagation delay?
The typical propagation delay is 1.0 ns under standard test conditions.
From: PHILIPS 74ABT16241A 74ABTH16241A 16-bit buffer/driver (3-State) handbook(1)
Do these devices require external pull-up resistors?
No, the bus-hold data inputs eliminate the need for external pull-up resistors to hold unused inputs.
From: PHILIPS 74ABT16241A 74ABTH16241A 16-bit buffer/driver (3-State) handbook
