Omron G6K Surface Mount Relay User Manual
This manual describes the G6K series surface‑mount relays, highlighting their ultra‑low profile (5.2 mm height, 6.5 mm width, 10 mm length) and lightweight construction (≈0.7 g). It lists electrical ratings such as 100 mW coil power, 1 500 V AC coil isolation, and high‑sensitivity contact performance.
The document also covers mechanical dimensions, packaging options (rod‑type 50 pcs per rod, tape‑type up to 900 pcs per roll), recommended soldering profiles, environmental limits (‑40 °C to +70 °C), and reliability testing procedures for vibration, shock, and life cycles. This manual is written in Chinese.
Omron G6K specifications
| Contact rating (max voltage) | AC 1,500 V |
|---|---|
| Electrical life | ≥ 100,000 cycles |
| Weight | ≈ 0.7 g |
| Operating temperature range | -40 °C to +70 °C |
| Operating humidity range | 5 % to 85 % RH |
All Omron G6K documents by type
Mounting, wiring and first power-up. Read it before the hardware goes in.
Disassembly, diagnostics and part numbers, for repair.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum voltage the contacts can withstand?
The contacts are rated for up to 1,500 V AC (10 × 160 Hz).
What is the insertion loss of the G6K(U)-2F-RF(-S) relay?
The insertion loss is 0.2 dB or less.
From: Omron G6K(U)-2F-RF(-S) Surface Mount High-Frequency Relay User Manual
How many relays are supplied per roll for the -TR03 tape packaging?
Each -TR03 roll contains 300 relays.
From: Omron G6K(U)-2F-RF(-S) Surface Mount High-Frequency Relay User Manual
What is the maximum coil voltage for the G6K relay?
The coil can withstand up to 1 500 V AC.
How many relays are supplied in a tape‑type roll?
A tape roll contains 900 relays, with a minimum order of 2 rolls (1 800 units).
How many relays are included in a tape roll?
A tape roll contains 900 relays.
