Omron G6B Power Relay User Manual
The Omron G6B series are compact power relays rated for 1 A‑5 A (8 A) loads with a low power consumption of 98 mW. They are offered in various contact configurations (1a, 1b, 2a, 2b) and coil voltages (5‑24 V DC) and include options such as ultrasonic cleaning, surge‑absorbing diodes and indicator LEDs.
The manual provides electrical and mechanical ratings, installation guidelines, wiring diagrams, and certification information (UL508, CSA, SEV). It also lists performance test results, dimensional drawings, and recommended mounting practices for reliable operation in industrial automation applications. This manual is written in Chinese.
Omron G6B specifications
| Contact rating (voltage) | AC250 V |
|---|---|
| Insulation voltage between coil and contacts | AC3,000 V |
| Minimum coil pulse width | 15 ms |
All Omron G6B documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What certifications does the G6B series have?
The G6B relays are certified to UL508, CSA and SEV standards.
What is the minimum coil pulse width for the relays?
The minimum coil pulse width is 15 ms at 23 °C.
What coil voltage range is available for the G6B relay?
The G6B relay can be ordered with coil voltages from 3 VDC up to 24 VDC.
What is the maximum switching current of the G6B relay?
The relay is rated for a maximum switching current of 5 A.
What is the power consumption of the G6B relay?
The relay consumes 98 mW of power.
What certifications does the G6B relay have?
It is certified to UL508, CSA and SEV standards.
