OMRON E2 ELITE HV-F127-E User Manual
The Omron E2 ELITE HV-F127-E is an electronic nerve stimulator designed for pain relief, muscle relaxation and improved blood circulation. The manual provides safety warnings, a description of the device’s features, and guidance on proper use.
It includes step‑by‑step instructions for inserting batteries, connecting the electrode cord, selecting treatment programs, and maintaining the unit, along with troubleshooting tips and full technical specifications.
Omron E2EL specifications
| Operating voltage | 10 to 35 VDC |
|---|---|
| Rated supply voltage | 24 VDC |
| Current consumption (max) | 15 mA at 24 VDC |
| Sensing object | Ferrous metals |
| Operating distance | 2.0 mm – 80 mm (model dependent) |
| Max load current | 200 mA |
| On‑state voltage drop | 2.5 VDC at 200 mA |
| Circuit protection | Reverse polarity, output short‑circuit |
| Indicator | Yellow LED |
| Ambient temperature range | -25 °C to 70 °C |
| Humidity range | 35 % to 95 % RH |
| Dielectric strength | 1500 VAC, 50/60 Hz for 1 min |
| EMC compliance | EN 60947‑5‑2 |
| Enclosure IP rating | IP67 |
| Vibration resistance | 10‑70 Hz, 1.5 mm double amplitude, 1 h each axis |
| Shock resistance | 300 m/s² (≈30 g) for 6 impacts per axis |
All Omron E2EL documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum load current for the E2EL sensors?
The sensors can handle a maximum load current of 200 mA.
What voltage range can the E2EL sensors operate at?
They operate from 10 VDC up to 35 VDC.
How long can the device operate before it turns off automatically?
The unit automatically switches off after 15 minutes of continuous treatment.
Can people with pacemakers use this stimulator?
No, the device should not be used by persons with medical implants such as pacemakers.
