Omron CP1H Manuals

ManualLib has 3 documents for the Omron CP1H (Automation control Equipment): 3 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 3

Key facts

Brand
Omron
Model
CP1H
Industry
Industrial
Documents
3
Languages
ZH · EN
Last added
2026-11-08

Start here

Omron CP1H-X40D / CP1H-XA40D / CP1H-Y20DT-D CPU Unit Operation Manual

Omron CP1H-X40D / CP1H-XA40D / CP1H-Y20DT-D CPU Unit Operation Manual

User Manual 641 pages · 14.9 MB · EN

This operation manual covers the SYSMAC CP Series CPU units CP1H‑X40D, CP1H‑XA40D and CP1H‑Y20DT‑D. It is intended for qualified operators and service personnel who need detailed information on unit features, system configuration, wiring, I/O memory allocation, and advanced functions.

The document includes sections on safety precautions, specifications, installation and wiring, basic and advanced functions, program transfer, debugging, troubleshooting, and maintenance. Appendices provide dimensions, memory maps, and revision history.

Read online

Omron CP1H specifications

GFMS-RM01S master controllerMaster Modbus RTU, 1 port
GFDI-RM01N digital inputDigital input, 16 channels
GFDO-RM01N digital outputDigital output, 16 channels / 0.5 A
GFPS-0202 power module24 V / 48 W
GFPS-0303 power module5 V / 20 W
0170-0101 adapter module8-pin RJ45 female connector / RS-485 interface
First GFDI-RM01N register address1000 (HEX)
First GFDO-RM01N register address2000 (HEX)

Source: OMRON CP1H Modbus RTU Connection Operation Manual

All Omron CP1H documents by type

User Manual 3

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

How do you connect an OMRON CP1H to Modbus RTU modules?

The CP1H is combined with the CP1W-CIF11 communication module, and the connection is configured with CX-Programmer software.

From: OMRON CP1H Modbus RTU Connection Operation Manual

What do the CP1W-CIF11 switches set?

Switch 1 sets the terminating resistor, switches 2 and 3 set the wiring type (ON for 2-wire, OFF for 4-wire), and switches 5 and 6 enable RS control.

From: OMRON CP1H Modbus RTU Connection Operation Manual

What software is used to program the Omron CP1H PLC?

The PLC is programmed with CX‑Programmer, part of the CX‑One suite, which runs on Windows.

From: Omron CP1H PLC Experiment Guide

How many communication cables are required for the lab setup?

Two cables are needed: one USB cable and one RS‑232C cable.

From: Omron CP1H PLC Experiment Guide
