Omron 3G3RV-ZV1 Variable Frequency Drive User Manual
This manual explains the safe handling, installation, and operation of the Omron 3G3RV-ZV1 series variable frequency drive. It includes general safety warnings, required precautions before installation, and guidelines for proper use to prevent electrical shock, fire, or equipment damage.
The document also details wiring connections, parameter settings, troubleshooting procedures, and maintenance requirements. It provides specific instructions for connecting power, grounding, emergency stop circuits, and how to adjust drive parameters for optimal performance. This manual is written in Chinese.
Omron G3R specifications
| Acceleration speed limit | 30 ts‑1s |
|---|---|
| Maximum operating temperature | 45 °C |
| Rated output current | 1.90 A |
| Rated power | 040 kW |
Source: Omron 3G3RV-ZV1 Variable Frequency Drive User Manual
All Omron G3R documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the recommended maximum temperature for the drive’s cooling system?
The drive’s internal temperature should be kept below 45 °C to avoid fire hazards.
What is the rated output current of the 3G3RV‑ZV1?
The rated output current is 1.90 A.
What is the maximum load voltage for the G3RZ‑201SLN relay?
It can handle up to AC 240 V or DC 100 V loads.
What is the leakage current when the contacts are open?
The open‑circuit leakage current is less than 10 µA.
What is the typical response time of the G3R-1/O relay?
The relay’s response time is specified as 20 ms or less, with some versions achieving 0.1 ms to 15 ms.
What insulation resistance does the relay provide between input and output?
The insulation resistance between input and output is at least 100 MΩ.
