OMRON CS1W-ETN01 (10Base-5) CS1W-ETN11 (10Base-T) CJ1W-ETN11 (10Base-T) Manual
This manual describes the installation, configuration and operation of the SYSMAC CS‑series CS1W‑ETN01 (10Base‑5), CS1W‑ETN11 (10Base‑T) and CJ‑series CJ1W‑ETN11 (10Base‑T) Ethernet Units. It provides detailed procedures for hardware setup, network parameters, IP address configuration, and the use of communication functions such as FINS, socket services, FTP server and mail.
The document also includes safety precautions, system‑setup memory allocations, testing methods, and a comprehensive troubleshooting guide. Technical specifications for each model are listed, including electrical requirements, dimensions, and environmental limits, to help users ensure proper integration into industrial automation systems. This manual is written in Chinese.
Omron E5CS specifications
| Type | 10Base‑5 (CS1W‑ETN01) / 10Base‑T (CS1W‑ETN11, CJ1W‑ETN11) |
|---|---|
| Baud rate | 10 Mbps |
| Transmission media | Coaxial cable (10Base‑5) / Unshielded twisted‑pair (UTP) cable (10Base‑T) |
| Maximum segment length | 500 m (10Base‑5) / 100 m (10Base‑T) |
| External power supply | 0.3 A min. at 24 VDC (per node) |
| Operating temperature | 0 °C to 55 °C |
Source: OMRON CS1W-ETN01 (10Base-5) CS1W-ETN11 (10Base-T) CJ1W-ETN11 (10Base-T) Manual
All Omron E5CS documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- OMRON CS1W-FLN02 (10Base-5)/CS1W-FLN12 (10Base-T) Manual 207 p
- OMRON CS1W-ETN01 (10Base-5) CS1W-ETN11 (10Base-T) CJ1W-ETN11 (10Base-T) Manual 315 p
- OMRON E5CSV/E5CS-U User Manual 108 p
- Omron E5CSV Temperature Controller User Manual 20 p
- Omron E5CSZ Temperature Controller Manual 19 p
- Omron E5CS Temperature Controller User Manual 20 p
Questions answered in these manuals
What is the purpose of the FL‑net Unit Support Tool?
The FL‑net Unit Support Tool provides overview, installation steps, computer‑to‑PLC connection guidance, and functions for configuring and testing the FL‑net units.
From: OMRON CS1W-FLN02 (10Base-5)/CS1W-FLN12 (10Base-T) Manual
What is the maximum baud rate of the Ethernet Units?
The Ethernet Units operate at a baud rate of 10 Mbps.
From: OMRON CS1W-ETN01 (10Base-5) CS1W-ETN11 (10Base-T) CJ1W-ETN11 (10Base-T) Manual
What type of cable is required for the CS1W‑ETN01 unit?
The CS1W‑ETN01 (10Base‑5) uses coaxial cable for transmission.
From: OMRON CS1W-ETN01 (10Base-5) CS1W-ETN11 (10Base-T) CJ1W-ETN11 (10Base-T) Manual
What sensor types can be used with the E5CSV/E5CS‑U controllers?
The controllers accept thermocouple, platinum resistance thermometer, or thermistor inputs.
How long does it take for the temperature display to become accurate after power‑on?
Approximately 30 minutes are required for the correct temperature to be displayed after turning the power supply on.
What is the supply voltage range for the E5CSV controller?
The controller operates from 100 to 240 VAC at 50/60 Hz, and a 24 VAC/VDC option is also available.
