Omron G6C Power Relay Service Manual
This service manual provides detailed information for Omron G6C power relays, including electrical ratings, contact configurations, and certification data. It also contains installation guidelines, wiring diagrams, and environmental limits.
The document lists the various G6C series part numbers, their UL/CSA certifications, and mechanical dimensions, and offers troubleshooting tips and safety precautions for proper use in motor, heater, and other power‑load applications. This manual is written in Chinese.
Omron G6C specifications
| Rated Current | 10 A |
|---|---|
| Rated Voltage | 250 VAC |
| Maximum Contact Voltage | AC 380 V, DC 125 V |
| Coil Power Consumption | 200 mW |
| Weight | ≈5.65 kg |
All Omron G6C documents by type
Disassembly, diagnostics and part numbers, for repair.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum current rating for the P6C socket?
The P6C socket is rated for a maximum current of 5 A.
What spacing is required when installing multiple relays side‑by‑side?
A minimum spacing of 2.54 mm × 3 (center‑to‑center) is required.
What is the maximum switching capacity of the G6C non‑latching relay?
The non‑latching G6C relay can handle up to 2,500 VA (300 W).
What is the contact resistance of the G6C relay?
The contact resistance is limited to 30 mΩ maximum.
What are the dimensions of the Omron G6C Power PCB Relay?
The relay measures 20.07 mm long, 14.99 mm wide and 9.91 mm high.
What is the maximum operating voltage for the G6C relay?
The relay can operate up to 380 VAC or 125 VDC.
