Start here
Omron G3DZ Power MOS FET Relay Service Manual
This service manual covers the G3DZ series power MOS FET relays, including both input‑resistance and non‑input‑resistance versions. It lists electrical ratings such as load voltage, load current, leakage current, and insulation resistance, and provides performance data like actuation time and reset time.
The document also includes mechanical dimensions, recommended wiring sockets, safety precautions, and environmental limits. Users can reference the conversion tables for model variants and find detailed graphs for load current versus temperature and input current versus actuation characteristics. This manual is written in Chinese.
Omron G3DZ specifications
| Load voltage (AC) | 125 V |
|---|---|
| Load current (AC) | 0.5 A |
| Open‑circuit leakage current | < 10 µA |
| Insulation resistance | ≥ 100 MΩ (DC500 V) |
| Output contact resistance | < 2.49 Ω |
| Operating temperature range | -30 °C to +85 °C |
| Weight | ≈ 3.1 g |
All Omron G3DZ documents by type
Disassembly, diagnostics and part numbers, for repair.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum leakage current when the relay contacts are open?
The open‑circuit leakage current is less than 10 µA.
What are the recommended input current values for the G3DZ relay?
The recommended maximum input current is 6.25 mA, and the action current should be below 4 mA.
What is the maximum leakage current when the output is open?
The leakage current is less than 10 µA.
What is the recommended input current for the relay?
The recommended input current is 6.25 mA, with a maximum of 50 mA.
