Omron G5RL Power Relay User Manual
This manual describes the electrical and mechanical characteristics of the Omron G5RL power relay series, including rated voltages, currents, contact resistance, and power consumption. It also lists environmental limits and certification standards such as UL, CSA, and VDE.
Installation dimensions, mounting hole sizes, and wiring diagrams are provided for various coil voltage options (DC5‑48 V, AC100‑240 V). The document includes performance data like contact ratings, switching frequency, and durability tests. This manual is written in Chinese.
Omron G5RL specifications
| Rated current (DC5) | 800 mA |
|---|---|
| Contact resistance | ≤ 100 mΩ |
| Coil power consumption | 0.075 W |
| Mechanical life | ≥ 10,000,000 cycles |
| Certifications | UL 508, CSA C22.2 No.1, No.14, VDE, DIN EN 61810‑1, EN 60255‑25 |
