Key facts
- Brand
- Omron
- Model
- CPM1A
- Industry
- Industrial
- Documents
- 4
- Languages
- EN
- Last added
- 2023-10-16
Start here
OMRON SYSMAC CPM1A Programmable Controller Operation Manual
The OMRON SYSMAC CPM1A is a compact, high-speed Programmable Controller (PC) designed for control operations in systems requiring from 10 to 100 I/O points per PC. This Operation Manual describes the system configuration, installation, and basic operating procedures for the Programming Consoles and SYSMAC Support Software (SSS). It serves as a primary guide for users to acquaint themselves with the CPM1A before attempting installation or operation.
The document covers the full lifecycle of the controller, including introduction to features and functions, unit specifications, installation and wiring precautions, usage of peripheral devices and programming consoles, and test run procedures. It also details error processing, troubleshooting flowcharts, maintenance inspections, and the use of the Expansion Memory Unit.
Omron CPM1A specifications
| Input voltage (AC model) | 120 VAC/DC nominal, range 85 to 132 |
|---|---|
| Maximum I/O points (with expansion) | Up to 100 points |
| Program capacity | 2,048 words |
| Weight (AC models) | 400 g max. |
All Omron CPM1A documents by type
Disassembly, diagnostics and part numbers, for repair.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Instruction set, parameters and examples for configuring or programming the device.
Questions answered in these manuals
What is the intended use of the CPM1A?
It is designed for control operations in systems requiring from 10 to 100 I/O points per PC.
From: OMRON SYSMAC CPM1A Programmable Controller Operation Manual
Which manual provides detailed descriptions of programming functions?
The CPM1/CPM1A/CPM2A/CPM2C/SRM1(-V2) Programming Manual (W353) provides detailed descriptions of the CPM1A's programming functions.
From: OMRON SYSMAC CPM1A Programmable Controller Operation Manual
What does the Z\DANGER symbol indicate?
It indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
What does the abbreviation PC stand for in this manual?
PC means Programmable Controller.
Which programming language is used by the CPM1A?
The controller is programmed using ladder diagram language.
How is the SRM1 described in the manual?
The SRM1 is a specialized programmable controller, normally called a CompoBus/S Master Control Unit, but it is programmed the same way as the other controllers.
