OMRON laser E3Z-LT E3Z-LR E3Z-LL amplifier Built-in laser photoelectricity sensor Manual
The Omron E3Z series includes through‑beam, retro‑reflective and BGS laser sensors designed for high‑precision detection. The manual describes the sensor’s optical features, power requirements, environmental ratings and mounting options.
Key sections cover safety guidelines, wiring diagrams, installation steps, operating instructions and detailed technical specifications such as beam spot size, detection range and IP rating. This manual is written in Chinese.
Omron E3Z specifications
| Beam spot diameter (through‑beam / retro‑reflective) | 5 mm (typical at 3 m) |
|---|---|
| Beam spot diameter (BGS type) | 0.5 mm (typical at 300 mm) |
| Maximum detection distance (through‑beam) | 60 m |
| Power supply | DC 12‑24 V |
| IP rating | IP67 |
Source: OMRON laser E3Z-LT E3Z-LR E3Z-LL amplifier Built-in laser photoelectricity sensor Manual
