Start here
Infineon XC886/888CLM 8-Bit Single Chip Microcontroller Data Sheet
The XC886/888CLM family is an 8‑bit single‑chip microcontroller based on Infineon's high‑performance XC800 core, compatible with the standard 8051 processor. It integrates on‑chip memory, multiple timers, ADC, UARTs, a CORDIC coprocessor, and a MultiCAN controller.
The datasheet provides a complete description of the device architecture, pin configuration, functional blocks, electrical parameters, and package dimensions, along with quality and reliability information for automotive and industrial variants. This manual is written in Chinese.
Infineon XC888CLM specifications
| CPU Core | XC800 Core, 8051 compatible |
|---|---|
| Boot ROM | 12 KB |
| RAM | 256 bytes |
| XRAM | 1.5 KB |
| ADC | 8‑channel, 10‑bit |
| Timers | Four 16‑bit timers (Timer0, Timer1, Timer2, Timer21) |
| I/O Supply Voltage | 3.3 V or 5.0 V (I/O), 2.5 V core |
| Temperature Range | SAF: –40 °C to 85 °C; SAK: –40 °C to 125 °C |
| Package Options | PG‑TQFP‑48 (XC886) and PG‑TQFP‑64 (XC888) |
Source: Infineon XC886/888CLM 8-Bit Single Chip Microcontroller Data Sheet
All Infineon XC888CLM documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What core architecture does the XC886/888CLM use?
It uses Infineon's high‑performance XC800 core, which is compatible with the standard 8051 processor.
From: Infineon XC886/888CLM 8-Bit Single Chip Microcontroller Data Sheet
What package types are offered for the XC886/888CLM?
Two package types are available: PG‑TQFP‑48 for the XC886 variant and PG‑TQFP‑64 for the XC888 variant.
From: Infineon XC886/888CLM 8-Bit Single Chip Microcontroller Data Sheet
What core architecture does the XC886/888CLM use?
It uses Infineon's high‑performance XC800 core, which is compatible with the standard 8051 processor.
What on‑chip memory sizes are available?
The device includes 12 KB of Boot ROM, 256 B of RAM, 1.5 KB of XRAM and up to 32 KB of Flash memory.
