Infineon SPP17N80C3 / SPA17N80C3 Power MOSFET Datasheet
Datasheet 13 pages · 613 KB · EN
The Infineon SPP17N80C3 and SPA17N80C3 are 800 V, 17 A Cool MOS power transistors offered in TO‑220 and Full‑PAK packages. The document provides maximum ratings, electrical characteristics, thermal data and typical performance curves.
Key sections cover maximum ratings, thermal resistance, on‑state resistance, capacitances, gate charge and safe operating area, along with package dimensions and legal notices.
All Infineon SPP17N80C3 documents by type
User Manual 2
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet 1
Ratings, dimensions and ordering codes, for selection and design work.
