Key facts
- Brand
- Analog Devices
- Model
- ADT7310
- Industry
- Industrial
- Documents
- 4
- Languages
- ZH · EN
- Last added
- 2022-09-11
Start here
ANALOG DEVICES UG-047 handbook
The document provides instructions for setting up the ADT7310/ADT7410 evaluation board, which includes a main board and a secondary board for remote temperature testing. It details the hardware connectors, indicator LEDs, and the process for connecting the boards to a PC via USB.
Read onlineAnalog Devices ADT7310 specifications
| Temperature Accuracy | ±0.5°C |
|---|---|
| Operating Temperature Range | -55°C to +150°C |
| Supply Voltage Range | 2.7 V to 5.5 V |
| Temperature Resolution | 0.0078°C (16-bit) |
| Package Type | 8-lead Narrow-body SOIC |
Source: Analog Devices ADT7310 High-Precision Digital Temperature Sensor Datasheet
All Analog Devices ADT7310 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the temperature accuracy of the ADT7310?
The temperature accuracy is ±0.5°C over a range of -55°C to +125°C at 3.0V.
From: Analog Devices ADT7310 High-Precision Digital Temperature Sensor Datasheet
What is the operating voltage range?
The device operates with a supply voltage between 2.7 V and 5.5 V.
From: Analog Devices ADT7310 High-Precision Digital Temperature Sensor Datasheet
What file must be run from the CD to install the software?
You must run the file AD7x10 Evaluation Software Install.exe from the evaluation kit CD.
Which switches must be set to the on position before starting the software?
Switch 3 and Switch 4 must be set to the on position.
What is the temperature resolution of the ADT7310?
The ADT7310 can be configured for 16‑bit resolution, giving a temperature step of 0.0078 °C.
What supply voltage range does the ADT7310 support?
It operates from 2.7 V up to 5.5 V.
