Analog Devices ADP1870/ADP1871 Datasheet
This document describes the ADP1870 and ADP1871 adjustable power‑management ICs. It includes functional block diagrams, pin‑out tables, and recommended operating conditions. The chips support input voltages from 2.95 V to 20 V and provide adjustable output voltages with high efficiency across a range of switching frequencies.
Detailed electrical characteristics, efficiency curves, thermal data, and package dimensions for MSOP and LFCSP variants are presented. Guidance on layout, such as connecting the exposed pad to ground, and compliance information (JEDEC standards) are also included. This manual is written in Chinese.
Analog Devices ADP1871 specifications
| Input voltage range | 2.95 V to 20 V |
|---|---|
| Supported switching frequencies | 300 kHz, 600 kHz, 1.0 MHz |
| Operating temperature range | -40 °C to +125 °C |
| Thermal resistance (MSOP) | 213.1 °C/W |
| Thermal resistance (LFCSP) | 40 °C/W |
All Analog Devices ADP1871 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the input voltage range of the ADP1870/ADP1871?
The devices operate with an input voltage from 2.95 V up to 20 V.
Which switching frequencies can be used with these ICs?
They support switching frequencies of 300 kHz, 600 kHz, and 1.0 MHz.
What is the input voltage range for the ADP1870/ADP1871?
The controller operates with a power input voltage from 2.95 V up to 20 V.
From: Analog Devices ADP1870/ADP1871 Synchronous Buck Controller Data Sheet
What is the minimum output voltage the controller can regulate?
It can regulate the output down to 0.6 V.
From: Analog Devices ADP1870/ADP1871 Synchronous Buck Controller Data Sheet
