Agilent U1731A/32A Handheld LCR Bridge User Manual
The Agilent U1731A/32A handheld LCR bridge provides high‑resolution (20,000 counts) measurements of resistance, capacitance and inductance with selectable test frequencies. It offers dual displays, optional backlight (U1732A), automatic phase‑angle calibration and data logging via an IR‑USB cable.
The instrument runs on a 9 V alkaline battery (≈40 mA draw) with typical battery life of about 7 hours, or can be powered from an AC adapter. It meets IEC safety and EMC standards and includes a three‑year warranty. This manual is written in Chinese.
Agilent U1731A/32A specifications
| Resolution | 20,000 counts |
|---|---|
| Display | Dual backlit display (U1732A) |
| Test Frequencies (U1731A) | 120 Hz, 1 kHz |
| Test Frequencies (U1732A) | 100 Hz, 120 Hz, 1 kHz, 10 kHz |
| Power Supply | 9 V alkaline battery (optional AC adapter) |
| Power Consumption | ~40 mA (battery) |
| Battery Life | ≈7 hours (typical) |
| Weight | 330 g |
| Dimensions (HxWxD) | 184 mm × 87 mm × 41 mm |
Source: Agilent U1731A/32A Handheld LCR Bridge Technical Data
All Agilent U1731A/32A documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the battery life of the U1731A/32A?
The instrument provides about 7 hours of operation on a typical alkaline 9 V battery.
What test frequencies does the U1731A model support?
The U1731A model can measure at 120 Hz and 1 kHz.
What test frequencies does the U1731A model support?
The U1731A supports 120 Hz and 1 kHz test frequencies.
How long does the battery last during typical use?
The battery provides about 7 hours of operation under typical conditions.
