Key facts
- Brand
- Agilent
- Model
- E8257D
- Category
- Other
- Industry
- Electronics
- Documents
- 2
- Languages
- EN
- Last added
- 2026-09-29
Start here
Agilent E8257DS02-S15 Source Modules User Guide
This document is the User's Guide for the Agilent E8257DS02, S03, S05, S06, S08, S10, S12, and S15 Millimeter-wave Source Modules. Although manufactured by Oleson Microwave Labs (OML), these modules are provided as an ordering convenience by Agilent Technologies.
The guide covers system setup, performance specifications, safety notes, and regulatory information. It also provides instructions for servicing, connector care, and electrostatic discharge protection, along with contact information for Agilent support and repair services.
All Agilent E8257D documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the frequency range of the Agilent E8257D?
It covers from 250 kHz up to 67 GHz, with operational capability up to 70 GHz.
From: Agilent E8257D PSG Microwave Analog Signal Generator Data Sheet
What is the output impedance of the generator?
The output impedance is 50 Ω nominal.
From: Agilent E8257D PSG Microwave Analog Signal Generator Data Sheet
Who manufactures the E8257DS02-S15 Source Modules?
The modules are manufactured by Oleson Microwave Labs (OML) and provided as an ordering convenience by Agilent Technologies.
What temperature range covers the product specifications for warranty?
Specifications describe performance parameters covered by the product warranty within a temperature range of +20 to +30 °C.
