Agilent 34980A Multifunction Switch/Measure Unit User's Guide
This document is the Chinese localized version of the User's Guide for the Agilent 34980A Multifunction Switch/Measure Unit. It provides instructions on operating the instrument, configuring measurement channels, and setting up various measurement modes such as scanning and monitoring.
The guide covers the instrument's front and rear panel layouts, menu references, and installation procedures. It details the use of SCPI language conventions, channel lists, and specific measurement configurations for voltage, current, resistance, temperature, and frequency. It also includes information on triggering, alarms, sequences, and remote interface configurations. This manual is written in Chinese.
Agilent 34980A specifications
| Maximum two‑wire channels | 560 |
|---|---|
| Maximum matrix points | 4096 |
| Maximum voltage | ± 300 V |
| Maximum switch current | 1 A |
Source: Agilent 34980A Multi‑Function Switch/Measure Unit User Manual
