PHILIPS PESD1LIN LIN bus ESD protection diode in SOD323 handbook
The document details the Philips PESD1LIN, a surface-mounted plastic package designed to protect one automotive LIN bus line from ElectroStatic Discharge (ESD) and other transients. It features an asymmetrical diode configuration optimized for Electromagnetical Immunity of a LIN Electronic Control Unit (ECU).
Read onlinePhilips SOD323 specifications
| Peak pulse power (Ppp) | 160 W at tp = 8/20 µs |
|---|---|
| Clamping voltage (VicLyr) | 40 V at Ipp=1A |
| Leakage current (Inv) | < 1 nA |
| ESD protection level | Up to 23 kV |
| Package type | SOD323 (SC-76) |
Source: PHILIPS PESD1LIN LIN bus ESD protection diode in SOD323 handbook
All Philips SOD323 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the peak pulse power capability?
The device supports a maximum peak pulse power of 160 W for an 8/20 µs waveform.
From: PHILIPS PESD1LIN LIN bus ESD protection diode in SOD323 handbook
What is the clamping voltage at 1A?
The clamping voltage is 40 V when the peak pulse current is 1 A.
From: PHILIPS PESD1LIN LIN bus ESD protection diode in SOD323 handbook
What are the applications of this rectifier?
It is suitable for low voltage rectification, high efficiency DC/DC conversion, switch mode power supply, inverse polarity protection, and low power consumption applications.
What is the maximum storage temperature?
The device can be stored between -65 °C and +150 °C.
