Key facts
- Brand
- Maxim
- Model
- MAX130
- Category
- Other Electronics
- Documents
- 15
- Languages
- EN
- Last added
- 2012-06-05
Start here
Maxim MAX130/MAX131 Datasheet
The MAX130 and MAX131 are 3‑digit A/D converters with onboard LCD display drivers and a bandgap‑referenced common voltage. They are pin‑compatible upgrades for the ICL7106 and ICL7136 and are offered in industrial temperature grades.
The document provides absolute maximum ratings, electrical characteristics, typical application circuits, and detailed design guidance such as component selection, capacitor recommendations, and overload handling.
Maxim MAX130 specifications
| Guaranteed Data Rate | 100 Mbps (VL > 1.8 V) |
|---|---|
| VCC Supply Range | +1.65 V to +3.6 V |
| Operating Temperature Range | -40 °C to +85 °C |
Source: Maxim MAX13013/MAX13014/MAX3023 Level Translator Datasheet
All Maxim MAX130 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
- Maxim MAX130/MAX131 Datasheet 12 p
- Maxim MAX13013/MAX13014/MAX3023 Level Translator Datasheet 18 p
- Maxim MAX13000E–MAX13005E 6‑Channel Level Translator Datasheet 25 p
- Maxim MAX13030E-MAX13035E 6‑Channel High‑Speed Logic‑Level Translator Datasheet 18 p
- Maxim MAX13042E-MAX13045E 4‑Channel Bidirectional Level Translator Datasheet 14 p
- Maxim MAX13046E/MAX13047E Low-Level Translator Datasheet 15 p
- Maxim MAX13055E–MAX13058E 8-Channel Bidirectional Level Translator Datasheet 14 p
- Maxim MAX13036 Automotive Contact Monitor and Level Shifter Datasheet 18 p
- Maxim MAX13037/MAX13038 Automotive Contact Monitor and Level Shifters with LDO Regulator Datasheet 22 p
- Maxim MAX13020/MAX13021 Datasheet 15 p
- Maxim MAX13051 +80V Fault-Protected CAN Transceiver Datasheet 12 p
- Maxim MAX13041 CAN Transceiver Datasheet 20 p
- Maxim MAX13085E RS-485/RS-422 Transceiver Datasheet 14 p
- MAXIM MAX13080E MAX13084E/MAX13086E MAX13089E handbook 24 p
Questions answered in these manuals
What temperature range can the MAX130/MAX131 operate in?
They are available in grades that cover –40 °C to +85 °C, and a version that covers 0 °C to 70 °C.
What data rate is guaranteed for the MAX13013/14/3023?
The devices guarantee a 100 Mbps data rate when the low‑voltage side (VL) is above 1.8 V.
From: Maxim MAX13013/MAX13014/MAX3023 Level Translator Datasheet
What are the allowed VCC and VL voltage ranges?
VCC may be between +1.65 V and +3.6 V, while VL may be between +1.2 V and (VCC ‑ 0.4 V).
From: Maxim MAX13013/MAX13014/MAX3023 Level Translator Datasheet
What data rate is guaranteed for the MAX13000E part?
The MAX13000E device is guaranteed to operate at 230 kbps.
From: Maxim MAX13000E–MAX13005E 6‑Channel Level Translator Datasheet
Does the device include ESD protection?
Yes, it provides ±15 kV ESD protection on the I/O VCC lines.
From: Maxim MAX13000E–MAX13005E 6‑Channel Level Translator Datasheet
What is the maximum data rate of the MAX13030E‑MAX13035E?
The device supports a guaranteed data rate of 100 Mbps.
From: Maxim MAX13030E-MAX13035E 6‑Channel High‑Speed Logic‑Level Translator Datasheet
