Start here
Maxim MAX19515 Dual-Channel 10‑Bit 65Msps ADC Datasheet
The MAX19515 is a dual‑channel, 10‑bit analog‑to‑digital converter offering up to 65 Msps sample rate and a wide 0.4 V‑to‑1.4 V input common‑mode range. It targets IF and baseband communications, ultrasound imaging, portable instrumentation, and digital set‑top boxes.
Key features include very‑low power consumption (43 mW per channel at 1.8 V), selectable data bus formats, programmable registers via SPI, and operation over –40 °C to +85 °C in a 48‑pin thin QFN package (7 mm × 7 mm). The datasheet provides absolute maximum ratings, electrical characteristics, timing diagrams, and pin configuration.
Maxim MAX195 specifications
| Resolution | 10 Bits |
|---|---|
| Maximum Sample Rate | 65 Msps |
| Input Common‑Mode Voltage Range | 0.4 V to 1.4 V |
| Analog Power Consumption (active) | 43 mW per channel at 1.8 V |
| Operating Temperature Range | -40 °C to +85 °C |
| Package | 48‑pin thin QFN, 7 mm × 7 mm |
| Signal‑to‑Noise Ratio | 60.1 dBFS at 70 MHz |
Source: Maxim MAX19515 Dual-Channel 10‑Bit 65Msps ADC Datasheet
All Maxim MAX195 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
- Maxim MAX19515 Dual-Channel 10‑Bit 65Msps ADC Datasheet 35 p
- Maxim MAX19516 Dual-Channel 10-Bit 100Msps ADC Datasheet 34 p
- Maxim Integrated MAX195 16‑Bit ADC Datasheet 28 p
- Maxim MAX19538 12‑Bit 95Msps ADC Datasheet 28 p
- Maxim MAX19586 16-Bit 80Msps ADC Datasheet 20 p
- Maxim MAX19588 16‑Bit 100 Msps ADC Datasheet 19 p
- Maxim MAX19505 Dual-Channel 8‑Bit 65Msps ADC Datasheet 35 p
- Maxim MAX19506 Dual-Channel 8‑Bit 100Msps ADC Datasheet 35 p
- Maxim MAX19507 Dual‑Channel 8‑Bit 130Msps ADC Datasheet 35 p
- Maxim MAX19515 Dual-Channel 10‑Bit 65Msps ADC Datasheet 35 p
- Maxim MAX19516 Datasheet 35 p
- Maxim MAX19517 Datasheet 35 p
- Maxim MAX19527 Datasheet 30 p
- Maxim MAX1954A Buck Regulator Datasheet 18 p
- Maxim Integrated MAX1954A Current‑Mode PWM Buck Controller Datasheet 18 p
- Maxim MAX1953/MAX1954/MAX1957 Datasheet 22 p
- Maxim MAX19517 Dual-Channel 10-Bit 130Msps ADC Datasheet 34 p
- Maxim MAX1953/MAX1954/MAX1957 Datasheet 22 p
- Maxim MAX1954A DC-DC Converter Datasheet 4 p
Questions answered in these manuals
What is the maximum sample rate of the MAX19515?
The MAX19515 can sample at up to 65 Msps.
From: Maxim MAX19515 Dual-Channel 10‑Bit 65Msps ADC Datasheet
How much power does the MAX19515 consume per channel in active mode?
It consumes only 43 mW per channel when powered at 1.8 V.
From: Maxim MAX19515 Dual-Channel 10‑Bit 65Msps ADC Datasheet
What is the maximum sample rate of the MAX19516?
The device supports a maximum sample rate of 100 Msps.
From: Maxim MAX19516 Dual-Channel 10-Bit 100Msps ADC Datasheet
What input voltage range does the MAX19516 accept?
It accepts a common‑mode voltage range from 0.4 V to 1.4 V.
From: Maxim MAX19516 Dual-Channel 10-Bit 100Msps ADC Datasheet
What is the maximum sampling rate of the MAX195?
The MAX195 can sample at up to 85 ksps.
How much current does the MAX195 draw in shutdown mode?
In shutdown mode the device draws a maximum of 10 µA.
