Maxim MAX174/MAX574A/MAX674A Datasheet
The MAX174, MX574A and MX674A are complete 12‑bit analog‑to‑digital converters that combine high speed, low power consumption and on‑chip clock and voltage reference. They support a variety of input ranges, including unipolar 0‑10 V, 0‑20 V and bipolar ±10 V, selectable by pin strapping.
These devices use a successive‑approximation technique and provide flexible digital interfaces (8‑, 12‑ or 16‑bit buses). External components are limited to decoupling capacitors and fixed resistors, making them suitable for applications such as high‑accuracy process control, high‑speed data acquisition and electro‑mechanical systems.
Maxim MAX174 specifications
| Resolution | 12‑bit |
|---|---|
| Power Dissipation | 150 mW |
| Conversion Time (MX674A) | 15 µs |
All Maxim MAX174 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the resolution of the MAX174 ADC?
The MAX174 provides a 12‑bit resolution.
How much power does the MAX174 consume?
The MAX174 dissipates 150 mW of power.
