Maxim MAX1205 14‑Bit 1Msps Single‑Supply ADC Handbook
The MAX1205 is a monolithic 14‑bit analog‑to‑digital converter that operates from a single +5 V supply and supports conversion rates up to 1 Msps. It uses a fully differential, pipelined architecture with digital error correction and an on‑chip self‑calibration routine that ensures 14‑bit linearity.
The document provides detailed electrical characteristics, pin descriptions, reference‑input requirements, calibration procedure, and typical performance graphs. It also includes application notes for imaging, communications, and data‑acquisition systems.
Maxim MAX120 specifications
| Resolution | 12-Bit |
|---|---|
| Throughput Rate (MAX120) | 500ksps |
| Throughput Rate (MAX122) | 333ksps |
| Conversion Time (MAX120) | 1.6us |
| Conversion Time (MAX122) | 2.6us |
| Power Dissipation | 210mW |
| Package Types | 24-Pin Narrow DIP, Wide SO and SSOP |
All Maxim MAX120 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
- MAXIM MAX120/MAX122 12-Bit ADCs Datasheet 16 p
- Maxim MAX1206 12‑Bit 40 Msps ADC Datasheet 29 p
- Maxim MAX1207 ADC Datasheet 29 p
- Maxim MAX1209 12‑Bit 80Msps 3.3V IF‑Sampling ADC Datasheet 27 p
- Maxim MAX1208 12-Bit 80Msps 3.3V ADC Datasheet 27 p
- Maxim MAX12000 GPS Front-End Amplifier Datasheet 9 p
- Maxim MAX12005 Satellite IF Switch Datasheet 14 p
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum throughput rate for the MAX120?
The MAX120 has a throughput rate as high as 500ksamples per second (ksps).
What is the maximum throughput rate for the MAX122?
The MAX122 achieves throughput rates of 333ksps with a 2.6us conversion time.
What supply voltage does the MAX1205 require?
The MAX1205 operates from a single +5 V supply.
How is the self‑calibration of the MAX1205 started?
Self‑calibration is initiated by asserting the ST_CAL pin high for at least four clock cycles.
What is the maximum sampling rate of the MAX1206?
The MAX1206 can sample at up to 40 Msps.
What supply voltage range does the MAX1206 operate from?
It operates from a single supply of 3.0 V to 3.6 V.
