Key facts
- Brand
- Maxim
- Model
- MAX161
- Category
- Other Electronics
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-07
Start here
Maxim MAX161/MX7581 CMOS 8-Bit Data Acquisition System Datasheet
The MAX161 and MX7581 are CMOS single-chip 8-bit, 8-channel data acquisition systems (DAS). Each chip includes an 8-bit A/D converter, 8-channel multiplexer, 8 x 8 dual port RAM with contention logic, and microprocessor compatible I/O logic. These devices interface directly with Z80/8085/6800 processors.
Read onlineMaxim MAX161 specifications
| Input Voltage Range | 5 V to 26 V |
|---|---|
| Off‑mode Current Consumption | 6 µA |
| Maximum Off Current | 6 A (max) |
| Package Pin Count | 8 pins |
| Transistor Count | 264 |
Source: Maxim Integrated MAX1614 High-Side N-Channel MOSFET Switch Driver Handbook
All Maxim MAX161 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
How many clock periods does a single channel conversion take?
A single channel conversion takes 80 input clock periods.
From: Maxim MAX161/MX7581 CMOS 8-Bit Data Acquisition System Datasheet
What is the input voltage range for the MAX1614?
The device operates from 5 V up to 26 V.
From: Maxim Integrated MAX1614 High-Side N-Channel MOSFET Switch Driver Handbook
How much current does the MAX1614 draw in off mode?
Off‑mode current consumption is only 6 µA.
From: Maxim Integrated MAX1614 High-Side N-Channel MOSFET Switch Driver Handbook
