Extech TP200 Type K Pipe Clamp Temperature Probe User's Guide
This document serves as the User's Guide for the Extech TP200 Type K Pipe Clamp Temperature Probe. It provides step-by-step operating instructions for connecting the probe to a compatible Type K measuring instrument and using the spring-loaded clamp jaws to measure pipe surface temperatures. The guide includes notes on ensuring accurate readings by keeping the probe surface free of dirt or substances that inhibit thermal contact.
Read onlineEXTECH TP200 specifications
| Datalogging capacity | 18,000 readings |
|---|---|
| Probe type | Type K thermocouple |
| IR measurement range | -4°F to 200°F |
| Distance to spot ratio | 8:1 |
| Resolution | 1°/0.1° |
| Dimensions | 7.9X2.9x1.9" (201 x 75x 50mm) |
All EXTECH TP200 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum surface temperature measurable with the included IR probe?
The included IR Thermometer Probe can measure non-contact surface temperatures up to 1022°F (556°C).
How many readings can the device datalog on each channel?
The instrument can datalog up to 18,000 readings on each channel.
What is the Extech TP200?
It is a Type K pipe clamp temperature probe used to measure temperatures on pipes.
From: Extech TP200 Type K Pipe Clamp Temperature Probe User's Guide
What pipe sizes can the Extech TP200 clamp onto?
The probe fits pipes with a diameter ranging from 0.25
