Key facts
- Brand
- EXTECH
- Model
- MN35
- Category
- multimeter
- Documents
- 2
- Languages
- EN
- Last added
- 2012-08-01
Start here
Extech MN35 Manual Ranging Mini Multimeter User's Manual
The document is a user guide for the Extech MN35 Manual Ranging Mini MultiMeter. It covers various measurement functions including AC/DC Voltage, DC Current, Resistance, Temperature (Type K thermocouple), Diode Test, Continuity, and Battery Test. The manual details safety precautions such as input limits and shock hazards.
Read onlineEXTECH MN35 specifications
| Maximum Input (VDC, VAC) | 600V DC/AC |
|---|---|
| Maximum Input (mA DC) | 250mA DC |
| Maximum Input (10A DC) | 10A DC (15sec. max every 15 min.) |
| Temperature Sensor Type | Type K thermocouple |
| Display Count | 1999 count LCD |
| Batteries Required | one 9V battery (NEDA 1604 or equivalent) |
Source: Extech MN35 Manual Ranging Mini Multimeter User's Manual
All EXTECH MN35 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum input limit for DC and AC voltage?
The maximum input limit for both VDC and VAC is 600V.
From: Extech MN35 Manual Ranging Mini Multimeter User's Manual
What type of thermocouple does the MN35 require?
The meter requires a Type K thermocouple for temperature measurements.
From: Extech MN35 Manual Ranging Mini Multimeter User's Manual
What is the difference between the MN35 and MN36 models?
The MN35 is a manual ranging model, while the MN36 is an autoranging model that supports AC Current, Capacitance, and Frequency measurements.
What is the maximum DC voltage measurement capability?
The multimeters can measure AC and DC Voltage to 600V.
