Key facts
- Brand
- Agilent
- Model
- Saturn 2000
- Category
- Other Electronics
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-12
Start here
Agilent Saturn 2000 Identification of Essential Oil Components by EI/MS Application Note
This application note presents a strategy to improve the qualitative identification of essential oil components using Gas Chromatography/Mass Spectrometry (GC/MS). The method combines Electron Impact (EI) mass spectrometry with a commercially available flavor and fragrance library and a secondary confirmation technique using Chemical Ionization (CI) with a 50:50 mix of acetonitrile and d3-acetonitrile.
Read onlineAgilent Saturn 2000 specifications
| Column | DB5 30m x 0.25 mm ID x 0.25um film |
|---|---|
| Injection Volume | 1 wL |
| Split Ratio | 20:1 |
| Carrier Gas Flow | 1 mL/min |
| Initial Temperature | 60°C |
| Final Temperature | 240°C |
| Ramp Rate | 3°C/min |
| MS AGC Target | 10,000 |
| Scan Range EI | 40-500u |
| Scan Range CI | 90-500u |
| Scan Rate | 1.0 sec/scan |
Source: Agilent Saturn 2000 Identification of Essential Oil Components by EI/MS Application Note
All Agilent Saturn 2000 documents by type
How to use the product for one specific task, with worked examples.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
What reagents are used for the dual CI confirmation?
A 50:50 mix of acetonitrile and d3-acetonitrile is used as the chemical ionization reagent.
From: Agilent Saturn 2000 Identification of Essential Oil Components by EI/MS Application Note
How is the essential oil sample prepared to avoid overloading?
The essential oils are diluted 50:1 in hexane and then split 20:1 in the injector.
From: Agilent Saturn 2000 Identification of Essential Oil Components by EI/MS Application Note
What are the space and weight requirements for the Saturn GC/MS components?
Table 1 in this document identifies specific dimensions (Height, Width, Depth) and weights for each component, such as the Saturn MS weighing 66 lb.
From: Agilent Saturn 2000 GC/MS Pre-Installation Instructions
What power sources are required for installation?
Two dedicated fourplex single-phase power sources with earth grounds hard-wired to the main power panel ground are required.
From: Agilent Saturn 2000 GC/MS Pre-Installation Instructions
