Key facts
- Brand
- Agilent
- Model
- 7000 Series
- Documents
- 15
- Languages
- ZH · FR · EN · DE · ES
- Last added
- 2026-10-15
Start here
Agilent 7000 Series Triple Quadrupole GC/MS System Quick Start Guide
The document serves as a quick reference for the Agilent 7000 Series Triple Quadrupole GC/MS System. It outlines the key hardware components, including the four-stage turbomolecular pump, electron impact source, and hexapole collision cell, as well as features of the MassHunter acquisition software. This manual is written in French.
Read onlineAgilent 7000 Series specifications
| Source Material | Quartz monolithic gold-plated |
|---|---|
| Mass Resolution (FWHM) | Selectable from 0.7 to 2.5 daltons |
| Detector Type | Triple Electron Multiplier (EM) |
| Vacuum System | Two-stage Turbomolecular Pump |
| MS Dimensions | 35 cm (W) x 86 cm (D) x 47 cm (H) |
| MS Weight | 59 kg |
Source: Agilent 7000B Triple Quadrupole GC/MS System Datasheet
All Agilent 7000 Series documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
- Agilent 7000 Series Triple Quadrupole Mass Spectrometer Pressure Controlled Tee Application Note 4 p
- Agilent 7000 Series Triple Quadrupole GC/MS Application Note for Phytoestrogen Analysis 8 p
- Agilent 7890A/7000 Series Triple Quadrupole GC/MS TCA Detection Application Note 4 p
- Agilent Maintaining Compound Retention Times with the Backflush Enabled Pressure Controlled Tee Configuration for Agilent 7890A GCs with Agilent 5975 Series MSD Agilent 7000 Series Triple Quadrupo 8 p
- Agilent 6890N/7000 Series GC/MS Application Note: Long-Term Detection of Anabolic Steroid Metabolites 8 p
The shortest path to a working setup, usually only a few pages.
Questions answered in these manuals
What is the primary function of the Agilent 7000 Series instrument described in this manual?
This manual provides operation and maintenance information for the Agilent 7000 Series Triple Quadrupole Mass Spectrometer (MS) system.
From: Agilent 7000 Series Triple Quadrupole GC/MS Operation Manual
What specific safety warnings are included in the introduction section?
The introduction covers general safety warnings and hydrogen safety operation information.
From: Agilent 7000 Series Triple Quadrupole GC/MS Operation Manual
Which software is used with this system?
The system uses Agilent MassHunter software for acquisition and analysis.
From: Agilent 7000B Triple Quadrupole GC/MS System Datasheet
What sample mass and extraction duration were used for the analysis?
The method uses 10g of sediment kept at 40°C for 48 hours before Soxhlet extraction.
What is the total run time for a single analysis?
The complete chromatographic run takes 40 minutes to complete.
What gas chromatograph is required for the Agilent 7000B system?
The Agilent 7000B system must be combined with the high-performance 7890A gas chromatograph.
From: Agilent 7000B Triple Quadrupole GC/MS System Data Sheet
