Key facts
- Brand
- Agilent
- Model
- 7673 ALS
- Documents
- 3
- Languages
- EN
- Last added
- 2012-06-08
Start here
Agilent 7673 ALS Installation Guide (18596-90197)
This document provides step-by-step procedures for replacing worn or sticky components on the Agilent 7673 Automatic Liquid Sampler. It covers the installation of three specific replacement kits: the Z-rod (Part No. 18596-61010), the Gripper Assembly (Part No. 18596-61005), and the Arm Assembly (Part No. 18596-61000). The guide details necessary tools, safety precautions regarding belts and gears, and specific removal steps for the tray quadrants and base.
Read onlineAll Agilent 7673 ALS documents by type
Disassembly, diagnostics and part numbers, for repair.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
What tools are required to install the replacement kits?
You will need a small flathead screwdriver, a No. 1 point Pozidriv, and a pair of needle-nosed pliers.
What specific parts can these replacement kits replace?
The kits are designed to replace a worn or sticky Z-rod, gripper assembly, or the tray arm assembly.
What is the purpose of this installation guide?
This document describes how to install a tray bracket on an Agilent 6890 Gas Chromatograph before installing an automatic liquid sampler.
What tools are required for this installation?
You need a T-20 Torx screwdriver and a flat-blade screwdriver to complete the procedure.
What part number replaces the old radial flex circuit?
The new circuit is available as part no. 18596-60915.
What modification must the turret have for this circuit to fit?
The turret must be modified by removing one sidewall from the flange.
