Key facts
- Brand
- Agilent
- Model
- 6890N
- Documents
- 29
- Languages
- ES · IT · FR · EN · DE · JA
- Last added
- 2012-07-09
Start here
Agilent 6890N Gas Chromatograph User Guide
This document is the User Guide for the Agilent 6890N Gas Chromatograph, published in April 2001. It provides comprehensive instructions for the preparation of the site, installation, and basic operational tasks such as controlling flow rates, pressures, and valves. The guide details the use of various injectors and detectors, including the Flame Ionization Detector (FID), Thermal Conductivity Detector (TCD), and Nitrogen-Phosphorus Detector (NPD). This manual is written in French.
Read onlineAgilent 6890N specifications
| Pneumatic Control Generation | Fourth generation electronic pneumatic control (EPC) |
|---|---|
| Maximum Injection Volume (PTV) | 500 µL in multiple injections |
| Maximum Injection Volume (Cold On-Column) | 50 µL in a single injection |
Source: Agilent 6890N Network Gas Chromatography System Product Brochure
All Agilent 6890N documents by type
- Agilent 6890N Network Gas Chromatography System Product Leaflet 16 p
- Agilent 6890N Network Gas Chromatography System Product Leaflet 16 p
- Agilent 6890N Network Gas Chromatography System Product Brochure 16 p
- Agilent 6890N Network Gas Chromatograph Specifications 4 p
- Agilent Gas Chromatographs Reference Guide 2 p
- Agilent 6890N Gas Chromatography System Catalog 40 p
How to use the product for one specific task, with worked examples.
- Fast Simulated Distillation Based on Agilent 6890N Gas Chromatograph Application Note 6 p
- Agilent Using a New Gas Phase Micro-Fluidic Deans Switch for the 2-D GC Analysis of Trace Methanol In Crude Oil by ASTM Method D7059 Manual 6 p
- Agilent 6890N Two-Dimensional Gas Chromatographic Analysis of Trace Benzene in Styrene Application Note 10 p
- Agilent 6890N Fast Determination of Denatured Fuel Ethanol Purity by Two-Dimensional Gas Chromatography Application Note 8 p
- Agilent 6890N Analysis of Trace Thiophene in Benzene Application Note 8 p
- Use of GC/MSD for Determination of Volatile Sulfur: Application in Natural Gas Fuel Cell Systems 10 p
- Agilent GC-MS Application Note for Methylmercury Determination in Tuna Fish 4 p
- Agilent GC/MSD Deconvolution Reporting Software Application Note 6 p
- Agilent 6890N/5973N Rapid Pesticide Analysis Application Note 12 p
- Agilent 5973/1100 Series Analysis of Components, Contaminants, and Impurities in Fungicide Formulations by GC/MS and LC/ 10 p
- Agilent 6890N/7000 Series GC/MS Application Note: Long-Term Detection of Anabolic Steroid Metabolites 8 p
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
How does the Electronic Pneumatic Control (EPC) improve performance?
The fourth-generation EPC maintains constant pressures and flows, providing excellent reproducibility of retention time.
From: Agilent 6890N Network Gas Chromatography System Product Leaflet
What is the maximum volume that can be injected in a single injection using the Agilent 6890N system?
The system allows injections of up to 50 pl in a single injection when using the cold on-column or programmable temperature vaporization injector.
From: Agilent 6890N Network Gas Chromatography System Product Leaflet
What is the maximum volume that can be injected in a single injection?
The system allows for injecting up to 50 µL with a single injection.
From: Agilent 6890N Network Gas Chromatography System Product Leaflet
How many times faster can real-time GC be compared to conventional systems?
Real-time gas chromatography can be performed up to ten times faster than with conventional GC.
From: Agilent 6890N Network Gas Chromatography System Product Leaflet
What pneumatic control technology does the Agilent 6890N use?
It uses fourth-generation electronic pneumatic control (EPC) to accelerate and facilitate pressure and flow settings.
From: Agilent 6890N Network Gas Chromatography System Product Brochure
Which detectors are compatible with the Agilent 6890N?
Compatible detectors include Mass Spectrometry (MSD), Flame Ionization Detection (FID), Thermal Conductivity Detection (TCD), and Atomic Emission Detection (AED).
From: Agilent 6890N Network Gas Chromatography System Product Brochure
