Key facts
- Brand
- Agilent
- Model
- G1330B
- Category
- Other Electronics
- Documents
- 2
- Languages
- FR · ES
- Last added
- 2012-06-08
Start here
Agilent G1330B Series 1200 Autosampler Thermostat User Manual
This manual covers the Agilent Series 1200 Autosampler Thermostat (Model G1330B), which utilizes Peltier elements for precise temperature control of sample vials. It details the device's operation, including the use of a special sample tray holding 100 vials or two 96-well plates. The thermostat functions by circulating air over the Peltier module to heat or cool the samples, with a dedicated leak removal system for condensation formed during cooling. This manual is written in French.
Read onlineAgilent G1330B specifications
| Sample Capacity | 100 vials of 1.8 ml or two 96-well plates and 10 vials of 1.8 ml |
|---|---|
| Operating Temperature Range | See Section 2 for specific ambient temperature requirements |
| Power Consumption | See Section 2 for specific power specifications |
Source: Agilent G1330B Series 1200 Autosampler Thermostat User Manual
All Agilent G1330B documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the purpose of the leak removal system?
The system directs condensed water from the cold side of the Peltier element safely to the leak removal system.
From: Agilent G1330B Series 1200 Autosampler Thermostat User Manual
How does the thermostat control temperature?
It uses Peltier elements to heat or cool air, which is then distributed evenly over the sample tray.
From: Agilent G1330B Series 1200 Autosampler Thermostat User Manual
What is the model number of this thermostat?
The specific model covered in this manual is G1330B.
From: Agilent G1330B Series 1200 Automatic Injector Thermostat User Manual
