Key facts
- Brand
- Agilent
- Model
- 35900E
- Documents
- 10
- Languages
- EN · FR · DE · IT · ES
- Last added
- 2012-07-05
Start here
Agilent ChemStation for GC Systems and 35900E A/D Converter Installation Manual
This manual provides instructions for installing the Agilent ChemStation software, integrating additional device modules into an existing system, and configuring the analysis system. It covers the installation of the software on PCs running Microsoft Windows XP Professional or Windows Vista Business, ensuring compatibility with various hardware requirements. This manual is written in German.
Read onlineAgilent 35900E specifications
| Memory | 1 MB RAM (expandable to 8 MB) |
|---|---|
| Weight | 4.1 kg (9 lbs) |
| Operating temperature range | 5 C to 40 C |
Source: Agilent 35900E Dual-Channel Interface with Modular Input/Output Datasheet
All Agilent 35900E documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Mounting, wiring and first power-up. Read it before the hardware goes in.
- Agilent ChemStation for CPG, Data Systems, and 35900E A/D Converter Installation Guide 70 p
- Agilent ChemStation for GC, Data Analysis and A/D Converter 35900E Installation Guide 70 p
- Agilent ChemStation for GC, Data Analysis and A/D Converter 35900E Installation Manual 70 p
- Installing the GPIB/RS-232 MIO Card into the Agilent Technologies 35900E Dual Channel Interface 4 p
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many lines are available on each Digital I/O channel?
There are 16 lines per channel, consisting of 8 bidirectional and 8 input-only lines.
From: Agilent 35900E Dual-Channel Interface with Modular Input/Output Datasheet
What is the physical width of the unit?
The device measures 325 mm wide.
From: Agilent 35900E Dual-Channel Interface with Modular Input/Output Datasheet
What is the operating temperature range?
The operating temperature range is from 5 °C to +40 °C.
From: Agilent 35900E Dual-Channel Interface with Modular Input/Output Datasheet
How much weight does the 35900E Dual-Channel Interface add to a setup?
The unit weighs 4.1 kg, which is equivalent to 9 lbs.
From: Agilent 35900E Dual-Channel Interface with Modular Input/Output Datasheet
How does EZChrom Elite communicate with the 35900E?
EZChrom Elite communicates with the 35900E over a LAN connection.
From: Agilent SS420x/35900E Analog/Digital Converter Migration Guide for EZChrom Elite CDS
Can the 35900E control an autosampler via BCD connector?
No, EZChrom Elite does not control the BCD connector used to control an autosampler.
From: Agilent SS420x/35900E Analog/Digital Converter Migration Guide for EZChrom Elite CDS
