Agilent 8453E UV-Visible Spectrophotometer System Quick Start Guide
This document provides a brief overview of the components included in the Agilent 8453E UV-Visible Spectrophotometer System. The kit includes a control module with connector cable, a PC card, sample holder, cuvette, spectrophotometer, and printer (not shown). It also lists the User Manual and Service Manual as separate documents.
The guide details the step-by-step assembly process for the system. This involves installing the sample holder into the instrument, connecting the control module via the CAN interface, plugging in the power cord (compatible with 100V to 240V), setting up the printer according to its manual and connecting it via the RS-232 interface, and finally powering on both the spectrophotometer and the HP printer. This manual is written in French.
Agilent 8453E specifications
| System Type | Standalone system comprising spectrophotometer and handheld controller |
|---|---|
| Spectrum File Extension | .wav |
| Kinetics File Extension | .csv |
Source: Agilent 8453E UV-visible Spectroscopy System Data Export Technical Note
All Agilent 8453E documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
The shortest path to a working setup, usually only a few pages.
Questions answered in these manuals
Can kinetics files be imported into Agilent ChemStation?
No, this feature is only applicable for spectrum files; you can import spectrum files but not kinetics files.
From: Agilent 8453E UV-visible Spectroscopy System Data Export Technical Note
What delimiter should be set when importing data into Microsoft Excel?
You must set Comma as the delimiter to separate different columns.
From: Agilent 8453E UV-visible Spectroscopy System Data Export Technical Note
What hazardous substances are restricted by RoHS/ELV regulations?
The regulated substances include cadmium (Cd), mercury (Hg), lead (Pb), hexavalent chromium (Cr(VI)), and brominated flame retardants (BFRs).
From: Agilent Technologies WEEE/RoHS/ELV Compliance Brochure
What are the EU limits for Lead (Pb)?
The EU limit for Lead in finished materials is 1000mg/kg (0.1%).
From: Agilent Technologies WEEE/RoHS/ELV Compliance Brochure
What voltage range is required for the Agilent 8453E system?
The power supply voltage must be between 100 V and 240 V.
From: Agilent 8453E UV-Visible Spectroscopy System Installation Guide
How do you connect the control module to the spectrophotometer?
Plug the connector cable into the appropriate CAN interface of the spectrophotometer.
From: Agilent 8453E UV-Visible Spectroscopy System Installation Guide
