Philips Semiconductors SC16C2550 Datasheet
Datasheet 46 pages · 186 KB · EN
The SC16C2550 is a 2-channel Universal Asynchronous Receiver and Transmitter (UART) designed for serial data communications. It converts parallel data into serial data and vice versa, handling rates up to 5 Mbits/s at 5 V and 3.3 V. The device features pin compatibility with the ST16C2550 and functional equivalence to the 16C2450.
Read onlineAll Philips SC16C2550 documents by type
User Manual 1
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet 1
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum serial data rate for this UART at 5 V and 3.3 V?
The device can handle serial data rates up to 5 Mbits/s when operating at 5 V or 3.3 V.
What is the maximum serial data rate for this UART at 2.5 V?
The device can handle a maximum serial data rate of 3 Mbits/s when operating at 2.5 V.
