The MAX19516 is a 10-bit, 100Msps dual-channel analog-to-digital converter (ADC) that supports DC-coupled inputs for a wide range of RF, IF, and baseband front-end components. It provides excellent dynamic performance from baseband to frequencies beyond 400MHz.
The MAX19516 is a dual‑channel, 10‑bit analog‑to‑digital converter that can sample at up to 100 Msps, supporting a wide 0.4 V‑1.4 V input common‑mode range and operating from a 1.8 V supply (or 2.5 V‑3.3 V with an internal regulator).
It delivers 60 dBFS SNR and 82 dBc SFDR, consumes only 57 mW per channel in active mode, and is offered in a compact 7 mm × 7 mm 48‑pin thin QFN package, making it suitable for RF, IF, baseband, ultrasound, portable instrumentation, and digital set‑top box applications.
| Maximum Sample Rate | 100 Msps |
|---|---|
| Resolution | 10 bits |
| Input Common‑Mode Voltage Range | 0.4 V to 1.4 V |
| Analog Power Consumption (active) | 57 mW per channel at 1.8 V |
| Package | 48‑Pin Thin QFN 7 mm × 7 mm |
| Signal‑to‑Noise Ratio | 60 dBFS |
The MAX19516 can sample at up to 100 Msps.
It accepts a common‑mode input voltage from 0.4 V to 1.4 V.
