The MAX19516 is a 10-bit, dual-channel, 100Msps ADC from ADI that operates from a 2.5V to 3.3V AVDD supply and accepts a wide 0.4V to 1.4V input common-mode voltage range. It supports DC-coupled inputs and can be used in a variety of RF, IF, and baseband front-end applications. The device has a typical signal-to-noise ratio (SNR) performance of 60dBFS and a typical spurious-free dynamic range (SFDR) of 82dBc at fIN = 70MHz and fCLK = 100MHz.
The MAX19516 is a dual‑channel, 10‑bit analog‑to‑digital converter offering a maximum sample rate of 100 Msps and a wide 0.4 V‑to‑1.4 V input common‑mode range. It operates from a 1.8 V supply (or 2.5 V‑3.3 V via an integrated regulator) and delivers low power consumption, with only 57 mW per channel in active mode.
Typical applications include IF and baseband communications, ultrasound imaging, portable instrumentation, and digital set‑top boxes. Ordering information and package details are provided, and Maxim offers support through its website and direct sales channels.
| Sample Rate | 100 Msps |
|---|---|
| Resolution | 10 bits |
| Input Common‑Mode Voltage Range | 0.4 V to 1.4 V |
| Analog Power Consumption | 57 mW per channel |
| Typical SNR | 60 dBFS |
| Typical SFDR | 82 dBc |
| Package | 48‑Pin Thin QFN, 7 mm × 7 mm |
The device supports a maximum sample rate of 100 Msps.
It accepts a common‑mode voltage range from 0.4 V to 1.4 V.
Typical SNR is 60 dBFS at 70 MHz.
It is offered in a 48‑pin thin QFN package measuring 7 mm × 7 mm.
