Key facts
- Brand
- Maxim
- Model
- MAX108
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-07-10
Start here
Maxim MAX104/MAX106/MAX108 Evaluation Kits
The document details the MAX104/MAX106/MAX108 Evaluation Kits (EV kits), which are designed to simplify the evaluation of the dynamic performance of these ultra-high-speed analog-to-digital converters (ADCs). Each kit contains all necessary circuitry, including power-supply generation for PECL termination voltage, and features a four-layer board layout optimized for high-speed analog and digital circuitry. The kits come fully assembled and tested with the respective ADC installed on the board with a heatsink.
Read onlineMaxim MAX108 specifications
| Conversion Rate | 1.5 Gsps |
|---|---|
| Full‑Power Input Bandwidth | 2.2 GHz |
| Effective Number of Bits (ENOB) | 7.5 bits at 750 MHz |
| Input Voltage Range | ±250 mV |
| Package | 192‑contact ESBGA (25 mm × 25 mm) |
Source: Maxim MAX108 ADC Datasheet
All Maxim MAX108 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the input signal range for the evaluation kits?
The input signal range is +250mV.
Do the kits include the ADC installed on the board?
Yes, the EV kits come with a MAX104/MAX106/MAX108 installed on the board with a heatsink attached.
What is the maximum sampling rate of the MAX108?
The MAX108 can sample at up to 1.5 Gsps.
What is the input voltage range for the analog inputs?
The analog inputs accept a ±250 mV signal range.
