Start here
Maxim Integrated Products MAX1002/MAX1003 Evaluation Kits Quick Start Guide
The document serves as a quick start guide for the MAX1002/MAX1003 Evaluation Kits (EV kits). These fully assembled and tested kits are designed to simplify the evaluation of the 60Msps MAX1002 and 90Msps MAX1003 dual, 6-bit analog-to-digital converters (ADCs). The guide outlines the necessary steps for connecting power supplies, configuring jumpers for gain selection, and setting up analog inputs.
Read onlineMaxim MAX1003 specifications
| Resolution | 6-bit |
|---|---|
| Analog Input Frequency | 20MHz |
| VCC Supply Requirement | +5V at about 65mA |
| MAX1003 Digital Output Supply | +3.3V |
| MAX1002 Digital Output Supply | +5V |
Source: Maxim Integrated Products MAX1002/MAX1003 Evaluation Kits Quick Start Guide
All Maxim MAX1003 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
The shortest path to a working setup, usually only a few pages.
Questions answered in these manuals
How do you disable the offset-correction amplifiers?
For DC-coupled applications, install shorting blocks on jumpers JU3, JU4 for the I channel and JU8, JU9 for the Q channel.
From: Maxim Integrated Products MAX1002/MAX1003 Evaluation Kits Quick Start Guide
What is the nominal VTUNE control voltage for setting the ADC sampling rate?
A nominal VTUNE control voltage of about 4V sets the ADC sampling rate to either 60Msps or 90Msps.
From: Maxim Integrated Products MAX1002/MAX1003 Evaluation Kits Quick Start Guide
What are the user-selectable input full-scale ranges?
The input amplifiers feature user-programmable input full-scale ranges of 125mVp-p, 250mVp-p, or 500mVp-p.
What is the typical channel-to-channel offset matching?
Matching performance between input channels is typically better than 0.1dB gain, 1/4LSB offset, and 0.5° phase.
What is the maximum sampling rate of the MAX1003?
The MAX1003 can sample up to 90 Msps per ADC.
What supply voltages does the MAX1003 require?
It requires a +5 V analog supply and a +3.3 V digital supply.
