EXTECH SDL500 Manuals

ManualLib has 4 documents for the EXTECH SDL500: 2 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 2

Key facts

Brand
EXTECH
Model
SDL500
Industry
Industrial
Documents
4
Languages
EN · ZH
Last added
2026-11-10

Start here

Extech SDL500 Hygro-Thermometer Datalogger User Guide

Extech SDL500 Hygro-Thermometer Datalogger User Guide

User Manual 12 pages · 300 KB · EN

The Extech SDL500 is a Hygro-Thermometer and Datalogger from the SD Logger Series that displays and stores temperature and relative humidity readings from a supplied probe, as well as temperature readings from an optional Type J or K thermocouple probe. It can also display Wet Bulb and Dew Point temperature calculations, and logged data is stored on an SD card for transfer to a PC.

This user guide covers the meter's description, power supply, probe connections, setup mode configuration (clock, sampling rate, auto power-off, beeper, numerical format, SD card formatting, temperature units, and thermocouple type), measurement procedures for relative humidity, temperature, and dew point, and data logging functions.

Read online

EXTECH SDL500 specifications

Power supplySix 1.5VDC AA batteries or optional AC adaptor
Thermocouple temperature rangeUp to 1300°C (2372°F)
Datalogger sampling rate1 to 3600 seconds
Auto power-off10 minutes of inactivity
Data storageSD card

Source: Extech SDL500 Hygro-Thermometer Datalogger User Guide

All EXTECH SDL500 documents by type

User Manual 2

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What thermocouple types does the SDL500 support?

The SDL500 accepts optional Type J or Type K thermocouple temperature sensors.

From: Extech SDL500 Hygro-Thermometer Datalogger User Guide

How long before the SDL500 automatically powers off?

With the auto power-off feature enabled, the meter switches off after 10 minutes of inactivity.

From: Extech SDL500 Hygro-Thermometer Datalogger User Guide

What is the maximum temperature the SDL500 can measure and display?

The instrument can measure and display temperatures up to 1300°C (2372°F).

From: Extech SDL500 Temperature and Humidity Meter User Manual

How long must you hold the power button to turn the instrument on or off?

You must hold the power button for at least 1.5 seconds to turn the power on or off.

From: Extech SDL500 Temperature and Humidity Meter User Manual

How long must I hold the power button to turn the meter on or off?

You must press and hold the power button for at least 1.5 seconds to power the meter on or off.

From: Extech SDL500 Hygro-Thermometer Datalogger User Guide

What is the maximum temperature the meter can display?

The meter can measure and display temperature up to 1300°C (2372°F).

From: Extech SDL500 Hygro-Thermometer Datalogger User Guide
