The Extech SDL500 Hygrometer/Datalogger is a portable data logger that measures relative humidity, temperature, dew point, and wet bulb temperature. It records data and stores it on an SD card for easy transfer to a PC for analysis. The data logger has an adjustable data sampling rate, an auto power off function, a backlit dual LCD display, and record/recall MIN, MAX readings functionality.
The Extech SDL500 is a Hygro-Thermometer/Datalogger that records data on an SD card in Excel format for easy transfer to a PC. It features relative humidity, temperature, dew point, and wet bulb measurement capabilities.
| Humidity Range | 5% to 95% |
|---|---|
| Temperature Range | 32 to 122°F (0 to 50°C) |
| Dew Point Range | -13.5 to 120.1°F (-25.3 to 48.9°C) |
| Wet Bulb Range | -6.9 to 122°F (-21.6 to 50°C) |
| Type K Temperature Range | -148 to 2372°F (-100 to 1300°C) |
| Type J Temperature Range | -148 to 2192°F (-100 to 1200°C) |
| Memory Capacity | 20,000K data records using 2G SD card |
| Dimensions | 7.2 x 2.9 x 1.9" (182 x 73 x 47.5mm) |
The device accepts Type K and Type J thermocouple inputs for high temperature measurements.
The Type K temperature range is -148 to 2372°F (-100 to 1300°C).
It stores 20,000K data records using a 2G SD card.
